PRODUCT
灌装机类别
装箱系统(开箱机、装箱机、封箱机)
AddTime:3/16/2012 11:12:46 AM
| DS-FX105开箱机case unpacker | |
| 适用纸箱Suitable carton | (L）200-500（W）150-420（H）100-500MM |
| 台面高度Height | 650 |
| 封箱速度Sealing speed | 500-720箱（ctns/hr） |
| 机械尺寸Size of machine | (L)2000(W)1900(H)1200mm |
| 使用电源Power supply | 220/380V single phase，50/60Hz |
| 使用气源Gas source | 5-6kg/cm2 150Ne/min |
| 使用胶带Adhesive tape | 48mm&75mm |
| 机械重量Weight of machine | 350kgs |
| DS-FX105装箱机case packer | |
| 该设备有是由伺服电机驱动，体积小，外形美观，工作稳定，方便操作；装载部分由无杆圆筒气缸驱动，高度可调节，夹子驱动高度可调This equipment is driven by servo motor. It is small, beautiful, stable and convenient to operate. The loading part is driven by stockless cylinder with height and driving height adjustable. | |
| 电源要求Power supply | AC 3P 380～400V,50HZ; control power AC220V |
| 控制电压Control voltage | P≥0.8Mpa, normal≥1M3 |
| 气源压力Pressure of gas source | 3.5kw |
| 重量Weight Production capacity | 1200kg |
| 生产能力 | 500 case /hour |
| 封箱机DS-FX105 | |
| DS-FX105型折叠式封箱机是包装流水生产线上的一个重要组成部分，该设备用于纸箱的上下侧封装，工作稳定，速度可调 BTM-FX105 folding type case sealer is an important part on packing production line. It is used for upper, down and side sealing carton. It works stable and the speed is adjustable. | |
